Breadboard-Friendly RGB Smart NeoPixel (Single)

This round PCB NeoPixel plugs directly into breadboards with dual 3-pin 0.1" headers for easy chaining—delivers 24-bit RGB color via 800kHz single-wire protocol, constant-current driver included. Perfect for first-year engineering students prototyping arrays or effects with Arduino (up to 500 pixels @30FPS).

5VDC (3.5–5.5V); ~55–60mA full white per pixel (SK6812 chip); 12.7×10.2×2.5mm. Solder headers if needed; 300–500Ω data resistor recommended.

Pins

VCC (5V), GND, DIN (data in), DOUT (data out).

Note: Product size and dimensions may vary. Sold individually.

Disclaimer: The images shown are for illustration purposes only and may not be an exact match.
